Power Supply 5 Vdc

‍

Power Consumption1700 mA @ +33 dBm TX Power
120 mA Standby
40 mA enabling Mode

‍

Connectors 15 pin FPC socket

‍

Communication Interface UART TTL port

‍

Baudrate 9600…921600 bit/s, 115200 bits/s factory default

‍

GPIO‍‍

2 Inputs TTL Levels:
Logic low:
< 0.8 V, minimum 0V
Logic high: > 2 V, maximum 3.3 V
2 Outputs TTL Levels:
Logic low: maximum 0.4 V
Logic high: minimum 2.9V, maximum 3.3
I : The maximum output current of the port is 5mA

Dimensions 93.5 × 80.3 × 8 mm

‍

Weight 118 g

‍

Material Aluminium

‍

Operating Temperature -25 °C … +55 °C

‍

Storage Temperature -40 °C … +85 °C

‍

Humidity up to 95 %, non-condensing

‍

‍

ISO Standard ISO 168000-63 (EPC Class 1 Generation 2)

x

Read Rate 350 – 1000  tags/s

x

Tag Cache ≥ 1000 Tags @ 12 Bytes EPC size

‍

‍

Supported OS Windows, Linux, Android

‍

Supported Languages C, C#/.NET, Java

‍

Demo Software Windows

‍

‍
