Mobile C9 – RED
Highlights
Spezifikationen
| Physical characteristics | |
|---|---|
| Dimensions | 170.8 × 81 × 20.4 mm ±2 mm |
| Weight | 400 g (including battery & wrist strap) |
| Display | Though 5.5 in. TFT-LCD | (720 x 1440) Touch screen with LED backlight |
| Battery | Rechargeable li-ion polymer, 3.8 V, 5.200 mAh* |
| Expansions | 2 PSAM, 2 SIM, 1 TF |
| Performance characteristics | |
| CPU | Cortex A53 2.0 GHz octa-core |
| RAM | ROM | 3 GB | 32 GB or 4 GB | 64 GB |
| Storage | MicroSD (max. 265 GB expansion) |
| Programming environment | |
| Operating System | Android™ 13 “Tiramisu“ |
| SDK | Online available |
| Language | Javascript |
| Environment | Android Studio or Android Eclipse |
| User environment | |
| Operating Temperature | -20 °C to +50 °C |
| Storage Temperature | -20 °C to +70 °C 5 % – 95 % RH (non-condensing) |
| Protection Class | IP65, IEC compliance |
| Drop Specifications | 5ft./1.5 m drop to concrete across the operating temperature range |
| ESD | ± 15 kv air discharge, ± 8 kv direct discharge |
| Camera | |
| Megapixel | Rear: 13.0 Megapixel | Front: 5.0 Megapixel |
| Flash | Autofocus with LED Flash |
| Communication | |
| WLAN | 2.4 GHz/5.0 GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac |
| WWAN | TDD-LTE Band 38,39,40,41 FDD-LTE Band 1,2,3,4,7,17,20 WCDMA (850/1900/2100 MHz) GSM/GPRS/Edge (850/900/1800/1900 MHz) |
| WPAN | Bluetooth Class v2.1 + EDR, Bluetooth v3.0 + HS, Bluetooth v4.2 |
| GPS | GPS (embedded A-GPS), accuracy up to 5 m |
| 2D Barcode Imager | |
| Honeywell N6703 2D Scan Engine Newland NLS-CM60/Newland NLS-N1 | |
| Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal, etc. |
| Supported standards | Tags | |
| ISO 18000-6C | Standard ISO 18000-6C (EPC Class 1 Generation 2) E.g.: Alien Higgs 2/3/4, Impinj Monza,NXP UCODE, etc. |
| ISO14443A and compatible | Read/write: Read UID only: all other ISO14443A RFID tags |
| ISO15693 and compatible | EM4135, EM4043, EM4x33, EM4x35, ICode SLI / SLIX, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (my-d vicinity |
| LEGIC | LEGIC RF-Standard: Read UID only (SM4200 chip):


 |
| LF: 125 kHz | ISO11785A and compatible |
| LF: 134.2 kHz | ISO11786A and compatible |
| PSAM security (optional) | |
| Protocol | ISO 7816 |
| Baudrate | 9600, 19200, 38400, 43000, 56000,57600, 115200 |
| Slot | 2 Slots (maximum) |
*battery power varies per product, duration and application
Beschreibung
Der leistungsstarke C9 RED ist eine wahre Revolution im Bereich der robusten Handheld-Computer. Sein 5,5-Zoll-Touchscreen mit einer Auflösung von 720*1440 erfüllt hohe Anforderungen in Logistik, Expressversand und Einzelhandel. Dank seines IP65-Gehäuses und einer Betriebszeit von bis zu 8 Stunden* ist er in der Lage, Daten in extremen und abgelegenen Umgebungen zu erfassen, zu extrahieren und zu analysieren. Der iDTRONIC Handheld-Computer eignet sich daher perfekt für Anwendungen im Außendienst, wie z. B. Luftfahrt, öffentliche Sicherheit, Bauwesen, Außendienstverkauf und Wartungssektor.
Der mit Android™ 13 “Tiramisu” betriebene C9 RED verfügt über einen leistungsstarken Cortex A53 2.0 GHz Octa-Core-Prozessor mit 4 GB RAM/64 GB ROM-Speicher. Das Gerät ist nur 20,4 mm dick und wiegt lediglich 400 Gramm inklusive Akku und Handschlaufe. Es sind verschiedene Handheld-Konfigurationen mit unterschiedlichen Barcode-Modulen verfügbar. Der C9 RED ist erhältlich mit UHF: 865 – 868 MHz / 920 – 925 MHz, HF – NFC: 13,56 MHz, nur NFC (13,56 MHz), LEGIC (13,56 MHz) oder LF: 125 oder 134,2 kHz. Er kann mit einem 2D-Barcode-Imager kombiniert werden, der eine einfache Bestandskontrolle und Berichterstellung ermöglicht.
Dank der eingebauten 13-Megapixel-Rückkamera mit Autofokus-Linse + LED-Blitz sowie einer 5-Megapixel-Frontkamera war die Schadensdokumentation im Wartungsbereich noch nie so einfach. Der C9 RED von iDTRONIC bietet Konnektivität, wo immer sie benötigt wird. Er verfügt über eine doppelte Absicherung durch 4G & WIFI-Netzwerk und ein hochsicheres Android 13.0-System, das eine schnelle Datenkommunikation und eine perfekte Sicherheitsgarantie bietet. Neben der Hardware bietet die C9 RED-Produktfamilie eine umfangreiche Dokumentation, Zubehör und Garantieerweiterungen, die Ihre Geschäftsanforderungen bestmöglich unterstützen.
